4 Man Crane Cage (1200x1100mm)

Sale!
Full Screen

4 Man Crane Cage (1200x1100mm)

Original price was: $4,154.08.Current price is: $3,655.59. plus GST

Code: SWP-C11A See specifications below.

In Stock

SKU: SWP-C11A Categories: , Tag:

Description

This crane cage work platform is designed and manufactured in accordance with AS1418.17 and are supplied with load test certificate, instruction manual and risk control measures. Fork pockets fitted for transport purposes only. This crane cage also comes with safety harness anchor points.  It has a hot-dipped galvanised protective coating.

This cage can also be manufactured to suit first aid rescue by fitting an outward opening gate. Please specify this when ordering.

Features:

  • Maximum capacity – 4 people
  • Working load limit – 500kg
  • Unit weight – 270kg
  • Fork pocket size – 165mm x 65mm
  • Fork pocket centres – 775mm
  • Overall Dimension – 1200mm wide x 1100mm deep x 1260mm high
  • Supplied with certified lifting chains.



Product Code WLL (kg) Unit Weight (kg) Fork Pocket Size (mm) Overall Dimensions (mm)
SWP-C11A 500 270 165 x 65 1200 wide x 1100 deep x 1260mm high



Let us do the heavy lifting for you

Want to learn more about our crane cages and raised work platforms?

Contact us now and be a step closer to reaching a solution best fit for your application.

Download the Product Spec below

Download

    Please enter your details below to download the specs & info...
