Balken INOX Stainless Steel Push Trolley

Balken INOX Stainless Steel Push Trolley zoom
Balken INOX Stainless Steel Push Trolley
Full Screen

Balken INOX Stainless Steel Push Trolley


See Specifications Above.

SKU: MTS Categories: ,

Description

  • Maximum protection against corrosive and high humidity environments.
  • Suitable for cleanrooms and food-industry applications.
  • All parts (except bearings) made from highly corrosion resistant 304(V2A) stainless steel. Bolts made from 2Cr13 stainless steel.
  • Customisable by adjusting the spacers.
  • Safety bars serve as fall-, breaking- and impact protection. Additionally equipped with tilting protection.
  • Permanently lubricated, ball bearing mounted wheels allow for smooth traversing.
  • Suitable for most I- and H-beam profiles.
  • Complies with the Machinery Directive 2006/42/EC. Supplied with test certificate, CE declaration of conformity and operating instructions.

Please complete the form below and one of our team members will contact you shortly:



SPECIFICATIONS
Operating Temperature -10°C – +60°C
Load Type Goods may not be used to lift people



PRODUCT CODE CAPACITY TEST LOAD SUITABLE BEAM WIDTH MINIMUM RADIUS WHEEL DIAMETER NET WEIGHT
Ton ton mm m mm kg
MTS-0-50 0.5 0.74 50-152 0.8 57 9
MTS-1-00 1 1.4 64-203 1 73 12
MTS-2-00 2 2.9 88-203 1.1 86 20
MTS-3-00 3 4.4 100-203 1.3 106 29
MTS-5-00 5 6.1 114-203 1.4 118 44

Balken INOX Stainless Steel Push Trolley Dimensions

PRODUCT CODE CAPACITY (ton) A B C D E G H J
MTS-0-50 0.5 199 68 30 119 104 245 32 25
MTS-1-00 1 246 84 27 145 127 327 40 30
MTS-2-00 2 276 97 27 171 156 345 52 38
MTS-3-00 3 332 119 37 200 178 367 63 40
MTS-5-00 5 377 131 38 228 198 378 75 50
