Adjustable Combination Spreader and Lifting Beam


See specifications below.

SKU: FSB-09 Categories: ,

Description

The Combination Lifting and Spreader Beam (otherwise known as an Adjustable Spreader Beam) is a unique multi-tasking beam which is designed to lift large and long loads via the centre single hook point as a ‘Lifting Beam’, or end lifted using a 2 leg chain sling as a ‘Spreader Beam’ with an overhead crane or forklift.

Features:

  • Can be lifted by forklift or crane
  • Load connection points are adjustable to 3 positions by moving the extendable arm in position
  • The 600mm long slipper pockets allow fast and safe connection to the truck
  • Safety pins included, used to securely lock extendable arm in position
  • Fitted with 2 safety swivel hooks
  • Certified to relevant AS Standards
  • Zinc finish on extendable arms, enamel paint finish on main body.

Let us do the heavy lifting for you

Want to learn more about our combination lifting and spreader beams?

Contact us now and be a step closer to reaching a solution best fit for your application.

Please complete the form below and one of our team members will contact you shortly:

Type Rated Capacity Fork Pocket Unit Weight (kg)
Used as a: Fully retracted
(LC@1200mm)
Middle position
(LC@1350mm)
Fully extended (LC@1690mm) Size (mm) Centre (mm)
FSB-09-120 Forklift attachment 4500kg 4000kg 3500kg 188 x 88 600 138
Lifting Beam 5000kg 4500kg 4000kg
Spreader Beam 6000kg 6000kg 6000kg



Type Rated Capacity Fork Pocket Unit Weight (kg)
Used as a: Fully retracted
(LC@2405mm)
Middle position
(LC@3165mm)
Fully extended (LC@3925mm) Size (mm) Centre (mm)
FSB-09-240 Forklift attachment 5600kg 2900kg 1400kg 185 x 85 900 260
Lifting Beam 6000kg 4500kg 2400kg
Spreader Beam 10,000kg 10,000 kg 10,000kg



Type Rated Capacity Fork Pocket Unit Weight (kg)
Used as a: Fully retracted
(LC@2920mm)
Middle position
(LC@3300mm)
Fully extended (LC@3680mm) Fully extended (LC@4060mm) Fully extended (LC@4440mm) Fully extended (LC@5000mm) Size (mm) Centre (mm)
FSB-09-300 Forklift attachment 4300kg 3000kg 2200kg 2000kg 1600kg 1000kg 188 x 88 600 276
Lifting Beam 4600kg 4200kg 3500kg 3200kg 2600kg 1800kg
Spreader Beam 10,000kg 10,000 kg 10,000kg 10,000kg 10,000kg 10,000kg

FSB-09-120

Spreader Beam - 1200m

FSB-09-240

Spreader Beams - 2400m

FSB-09-300

Spreader Beam - 3000mm
