Description
The Redline Series is used to change the direction of the rope, so the winch can be mounted in a convenient location and the Redline Lead Block will control the path of the rope to avoid obstacles, reduce hazard, and improve rope wear. For ropes between 1/4″ and 1/2″ in Diameter.
QUICK FACTS
- Up to 7,000 lb Line Load
- Cable Keepers on Top and Sides of Sheave
- Five Sizes for Different Rope Diameters
- Sealed Needle Roller Bearing with Grease Fitting
- Durable Powder Coat Finish
- Design in Accordance with ASME B30.26
- Two Year Warranty
FEATURES
Top and Side Cable Keepers
Provides additional security to prevent rope from jumping out of the sheave. Allows for a variety of rope configurations.
Large Diameter Sheaves
Large D:d ratios, to help reduce wear and tear on wire rope and extend rope life.
Sealed Needle Roller Bearings with Grease Fitting
Provide smooth rotation with load bearing strength for larger loads, couples with easy maintenance.
Low Profile Design with Wide Mounting Base
Provides strength and stability to support high load capacity in many configurations
Powder Coat Finish
Provides durable corrosion resistance for harsh environments.
Steel Sheaves
For added strength and long life.
