Description
We offer a wide variety of control options, from electric winch motor controls, winch remote control systems, single-speed motor controls for winches and variable speed motor controls for winches.
Electric Drum Control Switches
Single-Speed, Reversing-Drum Controls for 1- and 3-phase motors up to 7.5 hp
- UL and CSA Recognized components throughout.
- Enclosures to suit your application needs. NEMA 1 (industrial) rated switches provide protection against dirt and corrosion for most indoor applications. NEMA 4 (watertight) rated switches keep dirt and water out and are approved for most outdoor applications.
- Wiring Diagram is supplied inside the enclosure for convenient reference.
- Two-Year Limited Warranty
Variable-Speed Electric Motor Controls
For 3-phase, 230-VAC motors from 1 to 25 hp and 3-phase, 460-VAC motors from 1 to 60 hp. 10:1 Infinitely Variable-Speed Controls provide accurate positioning of loads, soft starts, soft stops, and overload protection.
- Frequencies greater than 50 Hz are possible in no-load or light-load conditions decreasing rigging time.
- Diagnostic and Troubleshooting Capabilities: digital display provides drive status.
- Programmable Performance keypad is adjustable to control acceleration and deceleration rates.
- Steel Enclosure is NEMA 12 rated (indoor). NEMA 4 rated (watertight) enclosures also available.
- Pendant Control Switch is NEMA 4X rated (watertight) with 3-step, infinitely variable-speed push buttons on a 50-foot cord, which allows the operator to stand away from the winch during operation. Pendant control is operated with momentary contact-type push buttons. Cord lengths of less than 50 feet are available.
- UL, IEC, or CSA Recognized components throughout.
- Electronic Thermal Overload Relay provides motor overload protection and is field programmable.
- Wiring Diagram is supplied inside enclosure.
- Options available include multiple axis, remote controls, mainline contact, disconnect switch, enclosure temperature controls, indicating lights, selector switches, horn and bells, meters, and limit switches.
- Explosion-Proof Controls also available.
- Two-Year Limited Warranty
Single-Speed Electric Motor Controls
Single-Speed, Reversing-Magnetic Controls for 1- and 3-phase motors up to 60 hp.
- UL, IEC, or CSA Recognized components throughout.
- Steel Enclosure is NEMA 4 rated (watertight) to keep the dirt and water out. Approved for most outdoor applications.
- Pendant Control Switch is NEMA 4X rated (watertight) on a 50-foot cord, which allows the operator to stand away from the winch during operation. Pendant control is operated with momentary contact-type push buttons. Cord lengths of less than 50 feet are available.
- Reversing Contactor is electrically and mechanically interlocked to deliver smooth reversing control.
- Thermal Overload Relay trips power OFF to protect motor from overheating. Switch is manually reset.
- Fused Control Circuit powers pendant with 115-volt, 2-amp current to help protect against high-voltage shocks.
- Wiring Diagram is supplied inside enclosure.
- Steel Mounting Bracket secures control box to winch.
- Explosion Proof Controls also available.
- Two-Year Limited Warranty
OPTIONS
- Special Current or Horsepower Ratings
- Special-Rated Enclosures for Explosive or Harsh Environments
- Multi-Speed Controls
- Torque-Limiting Controls
- Power Cord Disconnects
- UL-Listed Controls
- Various Selector Switches and Pilot Lights
Wireless Single-Speed Electric Motor Controls
Single-Speed, Reversing-Magnetic Controls for 1- and 3-phase motors up to 60 hp. In addition to the following, the wireless single-speed electric motor control has all the same features as the standard version, except for pendant-related features.
- Removes the limitations of a corded pendant's operating position.
- Rechargeable Wireless Transmitter
- A wireless transmitter is easily cloned, if lost.
- The winch can still be operated using the push buttons on the controller's receiver if the wireless transmitter is lost.
- The transmitter circuit board is epoxy-potted making it watertight and vibration-resistant
- Removes the limitations of a corded pendant's operating position.
- UL, IEC, or CSA Recognized components throughout.
- Steel Enclosure is NEMA 4 rated (watertight) to keep the dirt and water out. Approved for most outdoor applications.
- Reversing Contactor is electrically and mechanically interlocked to deliver smooth reversing control.
- Thermal Overload Relay trips power OFF to protect motor from overheating. Switch is manually reset.
- Wiring Diagram is supplied inside enclosure.
- Steel Mounting Bracket secures control box to winch.
- Two-Year Limited Warranty
OPTIONS
- Special Current or Horsepower Ratings
- Special-Rated Enclosures Torque-Limiting Controls
- Power Cord Disconnects
- UL-Listed Controls
- Various Selector Switches and Pilot Lights
