The VacuQuicklift is available in two main configurations: one designed for horizontal transport, and another with a tilting function for handling workpieces that require repositioning. All core functions—suction, lifting, lowering, and release—are controlled via a single, intuitive control lever. The system’s user-friendly operation, combined with its unique quick-release mechanism, ensures minimal cycle times and efficient handling.

Thanks to its modular design, the VacuQuicklift can be quickly and easily adapted to a wide range of applications and operational needs. It supports quick-change systems and offers a variety of suction pads, rotary units, and radio remote controls for the vacuum generators, allowing for maximum flexibility.

An optional extended control unit enables operators to handle workpieces at low or high elevations while maintaining an ergonomic posture, further improving comfort and safety. Naturally, it also includes the proven Quick Release system.

The VacuQuicklift is suitable for a broad range of applications, helping to simplify daily tasks, improve workplace safety, and significantly enhance process reliability. Wherever loads of up to 50 kg need to be lifted and moved repeatedly, the VacuQuicklift provides essential support, ensuring a highly efficient, ergonomic, and reliable workflow.

Areas of application:

• Picking cardboard boxes in logistics centers
• Transfers to/from and with stores of workpieces
• Board/sheet handling in wood and sheet metal processing
• Bricks and concrete components in the construction industry
• Loading and unloading of CNC processing machines
• Sacks in agriculture and bulk goods
• And much more!

Vacuum Generators

Vacuum Pumps	Silenced Pumps
Dry-running vacuum pumps with 25-40 m³/h and mounted vacuum filters are available for the VPL100-VPL140 series.	The dry-running vacuum pumps are also available in a silenced version, which ensures a significant reduction in noise.

Lifting Units

Lifting unit with fixed head	Lifting unit with swivel head
For purely horizontal handling or moving loads.	For horizontal and vertical handling or tipping of loads

Control Units

Control unit Quick Release
Suck - lift - lower - release: Control everything with just one control lever. It couldn’t be faster or easier.



MultiStacker control unit
For handling from high, medium or low altitudes. The control unit with joint and extension always ensures an ergonomic operating position.

Equipment Variants

Flange plate	Top quick release plate	Quick release plate below
Fastening base plate for the fixed installation of suction cups.	For screwing onto the control unit for changing suction pads during operation.	For screwing onto each suction cup, which means that these can be changed easily and quickly for different requirements.



Rotary device	Remote control	Pneumatics module
With optional locking module for every 90°. Turning of suctioned workpieces for stacking in changing layers.	Energy saving at the push of a button.  If desired, the vacuum generators can be easily controlled wirelessly.	An integrated compressed air supply is possible for special functions that require pneumatic functions.



Pneumatic switching module

For the independent control of pneumatic gripping units when loading or unloading.

Suction Cups

Single suction pads	Single suction pads	Sack suction cups
In round flat or bellows design for handling containers and barrels.	In a flat, rectangular design for small plates and workpieces with a solid surface.	With bellows suction cups and additional apron for sacks.



Sack suction cups	Double suction pad	Double suction pad
Lightweight plastic design with double seal for sacks.	With round bellows suction cups for smaller cardboard boxes and workpieces with curved surfaces.	With rectangular suction cups for medium-sized panels and rigid cardboard boxes.



Quadruple suction cups	Canister grabber	Universal hook grab
With round bellows suction cups. The suction cups are adjustable and clampable.  Suitable for large panels and cardboard boxes.	With balancing valve for handling canisters or containers with handles.	Mechanical hook gripper for hanging a wide variety of loads using crane hooks.



Mechanical lower gripper	Flat suction cups	High vacuum gripper
With compensating valve for handling loads by reaching under.	With automatic switching control when putting on for suction and release.	With pneumatic module, separate vacuum generator and manual slide valve for handling workpieces with small suction surfaces.



Combi-gripper	Canister gripper	Multigripper
With foldable lower grippers for packing racks in a box.	Mechanical bottom gripper for containers or canisters with handles or brackets.	Our Multigripper was specially developed for our VacuQuicklift tube lifter and can easily suction loads with different sizes and surface conditions.



Cardboard gripper	Bellows suction cups	Box gripper
With two bellows suction cups for optimal adaptation to surface curvatures.	With additional sealing insert for handling workpieces with slightly rough surfaces.	Mechanical gripper with clamp gripper for handling boxes and containers.
