Description
Niko offer a comprehensive range of modular steel components, enabling you to design and create your own custom overhead crane systems.
Key features include:
-
Custom Configuration: Design and build crane systems tailored to your specific space, height, and handling requirements.
-
Modular Steel Components: All components are made of high-quality steel for strength and durability.
-
Space-Efficient: Ideal for areas with height or space restrictions where conventional crane systems may not fit.
-
Reliable Handling: Enables safe and versatile overhead material handling across a wide range of applications.
-
Durable & Low Maintenance: Robust design and precision manufacturing ensure long service life with minimal upkeep
Track Profiles
 |
Track Profiles |
| The NIKO range includes six profile sizes, designed to handle loads of up to 2,000 kg. The enclosed, tapered track design ensures precise trolley alignment while minimising dust accumulation. This results in smooth trolley movement and extended crane lifespan. NIKO light cranes are highly efficient, requiring only 1–4% of the load weight to operate. |
 |  |
Unreinforced Track | Reinforced track with welded steel plate |
| The unreinforced track is designed to handle loads of up to 1000 kg. | Reinforced track with welded spine is a cost effective solution for relatively short spans or supporting distances. The welded spine reinforcement is also recommended for low head room requirement due to the low height of the spine. |
 |  |
Reinforced track with welded rectangular tube | Reinforced track with welded square profiles |
| Reinforced track with welded spine is a cost effective solution for relatively short spans or supporting distances. The welded spine reinforcement is also recommended for low head room requirement due to the low height of the spine. Powder coated tracks also available. | This type of reinforcements are necessary for long spans with fewer supporting points. AKA trussed, trellis or ladder type. |
Support Brackets
 |  |  |
Ceiling Support Bracket - (Code: B02) | Split Support Bracket - | Height Adjustable Support Bracket - (Code: B04) |
| This bracket is designed for bolting direct to overhead steelwork or ceiling. | This bracket is generally used for variable height configurations. | This allows us to adjust the height of the rails and to correct any misalignments. |
 |  | |
Adjustable wall bracket - (Code: B05) | Double adjustable wall bracket - (Code: B06) | Adjustable suspension bracket Dimensions - |
| This is used in combination with the .B04 adjustable bracket and it usually mounted on the wall. | It can accommodate two .B04 adjustable brackets. | This item is used for clamping the adjustable suspension bracket to the support steelwork and is supplied with a bolt and square nut. |
 |  |  |
Adjustable joist clamp with support bracket - Parallel - (Code: B35) | Adjustable joist clamp with support bracket - 90° - | Adjustable joist clamp with splice joint - Parallel - |
| Adjustable joist clamp with support bracket - Parallel to the I-Beam | Adjustable joist clamp with support bracket - 90° to the I-Beam | Adjustable joist clamp with splice joint - Parallel to the I-Beam |
 |  |  |
Adjustable joist clamp with splice joint - 90° - (Code: B72) | Height adjustable bracket - Parallel - (Code: B55) | Height adjustable bracket - Vertical - (Code: B56) |
| Adjustable joist clamp with splice joint - 90° to the I-Beam | Height adjustable bracket IPN DIN 1025 - Parallel to the I-Beam | Height adjustable bracket IPN DIN 1025 - Vertical to the I-Beam |
 |  | |
Adjustable bracket for I-Beam - (Code: Z10) | Height adjustable splice joint for I-Beam - (Code: Z16) | Height adjustable support bracket with |
| Adjustable bracket for the I-Beam | Height adjustable splice joint for I-Beam | Height adjustable support bracket with clamps for I-Beam |
 |
Height adjustable mounting assembly with plates for |
| Height adjustable mounting assembly with plates for I-Beam |
End Stops
 |  |  |
Track end stop - (Code: X01) | Safety bolt for track end stop with track punching - | Track end stop (safety bolt with rubber) - (Code: X11) |
| Track end stop | Safety bolt for track end stop with track punching (Track end stop not included) | Track end stop (safety bolt with rubber) |
 |
Track end stop - (Code: X41) |
| Track end stop (safety bolt with rubber), allowing cable trolley passage. |
Cable Trolleys & Clamps
 |  |  |
Cable end clamp - (Code: K01) | End Stop with Cable end clamp - (Code: K02) | Flat cable end clamp - |
| Cable end clamp. | End stop with cable end clamp | The flat cable end clamps are installed at the end of the conveyor system and guarantee the stability of the cable from the point of electric or hydraulic supply to the driven cable trolley. |
 |  |  |
Round cable or hose end clamp - (Code: K15) | Cable end clamp for hoses up to 120mm - (Code: K19) | Cable trolley (nylon) - |
| This round cable end clamp is installed at the end of the conveyor system and guarantees the stability of the cable from the point of electric or hydraulic supply to the driven cable trolley. | Cable end clamp for hoses up to 120mm | This trolley is used for carrying flat cable for electrical power supply and can be adapted for hoses and round cables. |
 |  |  |
Cable trolley (nylon) - | Flat cable trolley - (Code: L10) | Round cable or hose trolley - (Code: L15) |
| This trolley is used for carrying flat cable for electrical power supply. | Flat cable trolleys are suitable for the transport of flat cables of various dimensions | These trolleys are suitable for the transport of flexible cables and hoses of various dimensions. |
Trolleys
 |  |
4-Wheel trolley with clevis pin and buffer (plate) - | Heavy duty hoist trolley - (Code: T49) |
End Carriages
 |  | |
End carriage with double track joint - (Code: T53) | End carriage with track joint - Fixed - (Code: T54) | End carriage with track joint - Free - (Code: T74) |
| We can supply double carriages for overhead cranes for suspending two NIKO rails. | This range of trolleys is fitted with horizontal guide rollers and are used for connecting the bridge crane to the long travel tracks. For standard crane applications it is recommended that only one end carriage is fixed on the crane bridge allowing the other to move freely and compensate for track misalignment. | This range of trolleys is fitted with horizontal guide rollers and are used for connecting the bridge crane to the long travel tracks. For bridge length over 6 meters, longer end carriages are used. |
 |  |
End carriage with rotating track joint - (Code: T55) | Low headroom assembly for adjusting end carriages - (Code: T111) |
| End carriage with rotating track joint. | Low headroom assembly for adjusting end. End carriages are not included. |
